Phillips Flat Point Self Tapping Small Countersunk Screw

(inch) #0 #1 #2 #3 #4 #5 #6 #7 #8 #10 #12 1/4 5/16 3/8 7/16 1/2 P 48 42 32 28 24 20 20 19 18 16 14 14 12 12 10 10 dk max 0.112 0.137 0.162 0.187 0.212 0.237 0.262 0.287 0.312 0.362 0.412 0.477 0.597 0.717 0.76 0.815 dk min 0.096 0.12 0.144 0.167 0.191 0.215 0.238 0.262 0.285 0.333 0.38 0.442 0.556 0.67 0.715 0.765 k max 0.025 0.031 0.036 0.042 0.047 0.053 0.059 0.064 0.07 0.081 0.092 0.107 0.134 0.161 0.156 0.156 k min 0.018 0.023 0.028 0.033 0.038 0.043 0.048 0.053 0.058 0.068 0.078 0.092 0.116 0.14 0.133 0.13 M 0.062 0.07 0.088 0.096 0.11 0.122 0.14 0.148 0.168 0.182 0.226 0.224 0.31 0.358 0.386 0.402 No. 0 0 1 1 1 1 1 2 2 3 3 3 4 4 4 4 t max 0.036 0.044 0.049 0.056 0.071 0.082 0.067 0.075 0.095 0.11 0.104 0.119 0.148 0.196 0.225 0.241 t min 0.02 0.028 0.033 0.04 0.055 0.066 0.044 0.052 0.072 0.087 0.081 0.096 0.126 0.174 0.203 0.219 d max 0.06 0.075 0.088 0.101 0.114 0.13 0.139 0.154 0.166 0.189 0.215 0.246 0.315 0.38 0.44 0.504 d min 0.054 0.069 0.082 0.095 0.108 0.123 0.132 0.147 0.159 0.182 0.208 0.237 0.306 0.371 0.429 0.493 d1 max 0.036 0.049 0.064 0.075 0.086 0.094 0.104 0.115 0.122 0.141 0.164 0.192 0.244 0.309 0.359 0.423 d1 min 0.033 0.046 0.06 0.071 0.082 0.09 0.099 0.109 0.116 0.135 0.157 0.185 0.236 0.299 0.349 0.413 d2 0.031 0.044 0.058 0.068 0.079 0.087 0.095 0.105 0.112 0.13 0.152 0.179 0.23 0.293 0.343 0.407   Phillips Flat Point Self Tapping Small Countersunk Screws are designed for enhanced functionality and ease of use in various applications. Key features include: Size Range: Available in numerous sizes from #0 to #12, as well as fractional sizes like 1/4 and 5/16 inches. Strength Specifications: The screws offer a range of maximum and minimum values for both diameter and tensile strength, ensuring robust performance (e.g., dk max values ranging from 0.112 to 0.815). Durability: Constructed with precision, the screws have varying thicknesses (t max from 0.036 to 0.241 inches), suitable for different materials and settings, promoting durability under stress. Counter-Sunk Design: The countersunk head allows for a flush finish when installed, providing a clean appearance and reducing snag hazards. Self-Tapping Capability: These screws create their own holes during installation, making them ideal for quick and efficient fastening without pre-drilling. Distributors can leverage these features for delivering high-quality fastening solutions across diverse sectors.
