Amiko Mini 4K UHD Combo Receiver

DescriptionTuners & DemodulationTuner Type: DVB-T2 / DVB-C Frequency Range: 48 Mhz – 862 Mhz RF Input Level: “-80dBm to -20dBm” Antenna power output: DC 5V at max 75mA, Overload protection Demodulation: COFDM 1K, 2K, 4K, 8K normal and extended, 16K normal and extended, 32K normal and extended Input Symbol Rate: 1.0 ~ 7.0Ms/s Constellations: QPSK, 16QAM, 64QAM, 256QAM / Both rotated and non-rotated Guard Intervals: 1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128 Code Rate: 1/2, 3/5, 2/3, 3/4, 5/6Tuner Type: DVB-S / DVB-S2 Input Connector: F-type, Connector, Female Signal Level: -65 to -25 dBm LNB Power & Polarization: Vertical: 13V/ 14V, Horizontal: 18V/ 19V Current: Max. 400mA Overload Protection 22KHz Tone Frequency: 22±1KHz DiSEqC Control: Version 1.0, 1.1, 1.2, USALS Demodulation: QPSK, 8PSK Input Symbol Rate: 2-45 Mbps, FEC: 1/2, 2/3, 3/4, 5/6, 7/8 and AutoMPEG TS A/V DecodingTransport Stream: MPEG-2, MPEG-4, H.264, H.265 Input Rate: Max.120Mbit/s Aspect Radio: 4:3, 16:9, Letter Box Video Decoding: UHD 4K x 2K, HEVC/H.265, MPEG-4/H.264 SP@L3 to ASP@L5, MP@ML, MP@HL, [email protected], [email protected] Video Resolution: 720*480p/i, 720*576p/i,1280*720p, 1920*1080p/i, 3840 *2160p Audio Decoding: AAC-LC, HE-AAC, LPCM, MP3, WMA, WAV Audio Mode: Left / Right / Stereo/ Mono Sampling Rate: 32, 44.1 and 48KHzSystem ResourcesMain Processor: 1000 MHz Flash Memory: Serial Flash 8MB x 1 DDR RAM: DDRIII 1866 128MBx2A/V & Data Input/OutputEthernet: 10/100M RJ45 USB: Two USB 2.0 slot Compatible Digital Video Output S/PDIF: Coaxial Digital Audio or Dolby Digital Bit Stream Output SCART: (1-CVBS, 1-L/R,SL,FB),or RCA output IR: Jack-type, External IR sensor connection RS232: Jack-type, Transfer rate 115.2Kbps, 9 pin D-sub TypePhysical SpecificationsSize[W*H*D]: 146mm*110mm*35mm Net Weight: 0.25 Kg Operation Temperature: 0°C~ 45°C Storage Temperature: -10°C~ 70°C Storage Humidity: 5%~95% RH (Non-Condensing)
